Meister G3. Surface and Profile CNC Surface Grinding Machine

Meister G3. Surface and Profile CNC Surface Grinding Machine

Meister G3. Surface and Profile CNC Surface Grinding Machine

Meister G3 - universal surface and profile grinder for high speed ultra-precision grinding of small parts. Up to 500 strokes per minute, super precision spindle and sub-micron slide control makes the G3 the most productive grinder of its type. Rigid construction with double V table slideways, temperature controlled with unique AMADA Wasino software for ease of operation and setting, to grind the flattest parts with very high surface quality to fully formed wheels and profile grinding. CMC dressers, measuring probe, cylindrical attachments and NC indexers make the G3 a fully universal surface and profile grinder.

Enquire Now
General Information

Meister G3. Surface and Profile CNC Surface Grinding Machine Information

Meister G3. Surface and Profile CNC Surface Grinding Machine For more information please call us on 02476 375442 for more details.

Machine Specifications

Meister G3. Surface and Profile CNC Surface Grinding Machine Machine Specifications

Amada Meister-G3 - Specifications
CAPACITY
Table Working Surface W x L 21.65" x 7.87"
Spindle Center Height from Table 3.54" ~ 15.75"
Standard Chuck Size 15.75" x 7.87" x 3.94"
Workpiece ----
Wheel size OD x W x ID 8" x 0.25" ~ 1" x 1.25"
Wheel Spindle (AC Inverter) 3hp
  3-axis, cross & vertical, 2 axis simultaneous + Table




Downloads

Meister G3. Surface and Profile CNC Surface Grinding Machine Downloads

Below are the technical downloads for this product, have any further questions? Please contact us.
